Vamp Flex Tester i9 (Digital)
100 INR/Unit
Product Details:
X
Vamp Flex Tester i9 (Digital) Price And Quantity
- 10 Unit
- 100 INR/Unit
Vamp Flex Tester i9 (Digital) Trade Information
- Delhi
- 3-4 Week
- Contact us for information regarding our sample policy
- All India
- ISO Certified
Product Description
Vamp Flex Tester double creases similar to those formed in the upper of a boot during wear aregenerated repeatedly in specimens of poly (vinyl chloride) upper material by means of a suitableapparatus until cracking of the poly (vinyl Chloride) upper material is observed or until the test piecessurvive a specified number of flexure cycles.Paramount Vamp Flex Tester i9 is an ergonomically designed Equipment with sturdy mechanism toget Accurate & Reliable Results. It consists of specified size of pairs of V-shaped clamps suitably mountedso that the axis of each pair are in the same straight line. The tips of each V-clamp are rounded to aspecified radius. The number of flexing cycles is indicated and control by the digital preset counter.
| Surface Finish | Blue Powder Coated |
| Brand | Paramount |
| Voltage | 220v |
| Country of Origin | Made in India |
| Material | Mild steel |
SALIENT FEATURES
- To determine the propensity for materials to Crack or otherwise fail at flexing creases. Equally suitable for testing leather, plastic coated fabrics, woven fabrics to test seam construction during flexing
- In particular the test simulates conditions in the vamp Part of footwear during walking. Vamp is the arched upper surface of the human foot between the toes and the ankle
- Sturdy & Ergonomic Equipment for Accurate & Reliable Results
- 4 Samples can be tested at a time
- Precision Engineered components for continuous operations
- Adheres to National & International Standards
TECHNICAL SPECIFICATIONS
- No. of sample test at a time: 4
- Sample size: 64 x 64mm
- Angle of each V-clamp: 40 +/- 1
- Radius of Tip of V: 6.4 +/- 0.5mm
- Clamp: 40 V shaped
- Flexing Speed: 300 +/- 30 Cycles per Minute
- Counter: Programmable 6 digits DIGITAL Counter
- Speed of Clamp: 300rpm & 90 rpm
- Motor : 1/2 HP, 220V AC single phase induction motor
- Power: 500W, 220 VAC single phase
- Overall Dimensions: LENGTH x DEPTH x HEIGHT 1020mm x 600mm x 620mm / 41.3 x 16.7 x 21.6
- Net Weight of the Instrument: 70 kg (154 lb.)
