GSM i9 Round Cutter
100 INR/Unit
Product Details:
- Dimension (L*W*H) 160x160x110 Millimeter (mm)
- Weight 1.7 Kilograms (kg)
- Application Industrial
- Click to View more
X
GSM i9 Round Cutter Price And Quantity
- 10 Unit
- 100 INR/Unit
GSM i9 Round Cutter Product Specifications
- 1.7 Kilograms (kg)
- 160x160x110 Millimeter (mm)
- Industrial
GSM i9 Round Cutter Trade Information
- Delhi
- Paypal Letter of Credit (L/C) Telegraphic Transfer (T/T) Days after Acceptance (DA) Cash on Delivery (COD) Western Union Letter of Credit at Sight (Sight L/C) Delivery Point (DP) Cash Against Delivery (CAD) Cash in Advance (CID) Cheque Cash Advance (CA)
- 3-4 Week
- Contact us for information regarding our sample policy
- All India
- ISO Certified
Product Description
Round Cutter is an instrument to determine the GSM of the fabric (Woven, Non-Woven, Knitted, Paper & Packaging etc.) It can be used for virtually any type of material including film, foam, carpet, paper, board etc.
Paramount Round Cutter for GSM i9 is a High-Quality Equipment completely made of very fine aluminum casting for light weight & resilience. The Equipment has diamond studded locking (Catch lock) mechanism for safety. The instrument is equipped with a set of four replaceable German blades and all the four sides of the blades can be used. Two specially designed standard grey-cutting pads provided to support the cutting operation. The equipment is meticulously finished with Blue PU paint. The equipment is recommended for yield testing i.e. weight per unit area. It cuts rapidly and accurately circular specimen of 100 cm2 is which gives the GSM directly
SALIENT FEATURES
- Ergonomic latest design sample cutter
- Finest grade of aluminium metal used in the main body for light weight and robustness minimum fatigue factor for operator
- Smooth precision engineered components for exceptional performance
- Easy to use, diamond studded locking mechanism
- Stainless-Steel blade holders for lifelong trouble-free operations
- Special rubberized foam cutting pad for smooth cutting and long life of the blades
- Supplied completely with Calibration Certificate (Traceable to NPL)
TECHNICAL SPECIFICATIONS
- Size of the sample dia. to be cut: 113mm
- Cutting blades: Reversible i.e. can be used from all four sides.
- No. of Cutting Blades: 4 Nos (1 Set Fitted)
- Movement of hand wheel: 1/4 rounds to cut a specimen
- No. of cutting pads: 1 No.
- Size of grey cutting pads (mm): Length x Depth x Height 300mm x 200mm x 23 mm
- Overall Dimensions of the Instrument: 160mm x 160mm x 110 mm
- Net Weight of the Instrument: 1.7 kg. (3.74 lbs)
| Diameter | 160 mm,61/4 Inch |
| Height | 110 mm,4.33 Inch |
| Length | 160 mm,4.56 Inch |
| Model No. | GSM-Cutter-i2 |
| Sample Cut | Round |
| Brand | Paramount |
| Display Type | Digital |
| Usage/Application | Industrial |
