Digital Bursting Strength Tester

Product Description

Paramount Bursting Strength Tester i9 (DIGITAL, 40KG) has a sturdy body having a specially designed clamp to hold the fabric for bursting test .A test specimen is held between two annular clamps under sufficient pressure to minimize slippage. The clamping is done by a convenient hand wheel arrangement . A circular diaphragm of special rubber is clamped between the lower clamping plate The upper clamping surface, which is in contact with the test specimen, has a continuous spiral groove and the lower clamping surface has a number of concentric grooves to minimize the slippage of specimen. The equipment is fitted with an advanced motor driven cam mechanism, which increases fluid displacement on the lower side of the Diaphragm at a specified rate.The equipment has an auto arrangement, which automatically brings down the pressure and stops the motor on completion of the test cycle. A digital, microprocessor-based control panel has digital display with peak value & zero setting. The equipment is beautifully finished in Blue powder coated paint for modern aesthetics.

SALIENT FEATURES

• Specially designed equipment to determine bursting strength of knitted fabric/ Medical Textile/ Non-Wovens/ leather/ paper ,cardboard ,fibre board etc
• Latest design with a microprocessor-based control panel with digital display
• Maximum capacity 40 kg
• Glycerine is used as test fluid
• Smooth precision engineered components for excellent performance
• Adherence to national & international Standard
• Complete with all accessories including spare Diaphragm
• Supplied complete with Calibration Certificate (Traceable to NPL)
