Crockmeter i9 ( DIGITAL)

Product Description

Rubbing Fastness Tester i9 ( Motorized ) is a next generation Rubbing Fastness Tester for all type of textile (fabrics ,Garments, home textile etc.

Paramount Rubbing Fastness Tester i9 (Motorized) is an advanced Microprocessor based version of Rubbing Fastness tester which is operated automatically by a motor as per standard requirements. It has an aerodynamic design with customer friendly features. It consists of the Main Unit having an Oscillating Arm with a Finger, which Rubs over the Test Specimen under a specified Load over the Test Specimen. The rubbing finger is cylindrical in shape and has a flat base, which is covered with a piece of standard white Crocking cloth which picks up the color lost by the test specimen. The Crocking cloth is held over the finger with the help of a Stainless-Steel Spring Clip. Motion to the finger is given by the Oscillating arm, which runs on bearing free Teflon rollers to minimize friction and to give uniform load on the finger. The Oscillating arm is moved with the help of a Geared motor with instant braking (specially developed by Paramount (R&D)). The equipment is finished in fine Blue and Gray paint.

SALIENT FEATURES

• Rubbing Fastness Tester i9 ( Motorized ) is a next generation Rubbing Fastness Tester for all type of textile (fabrics ,Garments, home textile etc
• The central panel is microprocessor based programmable unit
• The rubbing finger is easy to load with crocking cloth by using a spring clip
• Dual sample holder for specimen and garment Testing
• The weight to produce a load of 9N is removable and alternative weights(22N) can also be used for furnished fabrics
• Steel & acrylic Sample Holder for rapid sample mounting
• Microprocessor-based counter to show the number of rubbing cycle
• Precision engineered components for smooth operation
• Adherence to national & international Standard
• Supplied complete with Calibration Certificate (Traceable to NPL)

 TECHNICAL SPECIFICATIONS

• Diameter of the finger: 16 mm+/-0.2 mm
• Force on the Finger: 9 Newtons.
• Size of Crocking Cloth: 5 x 5 cm
• Dia. Of the finger (For all fabric and textile): 16 mm
• Dia. Of the finger (For Furnishing Fabrics): 25 mm
• Force on the Finger (For Furnishing Fabrics): 22 Newtons.
• Size of crocking Cloth (For Furnishing Fabrics): 7 x 7 cm
• Length of the Traverse of the finger: 104 +/- 3 mm
• Microprocessor-based counter: 0 -999, (Least Count: 1)
• Overall Dimension of the Unit: 725mm x 305mm x 305 mm /28.5 x 12 x 12
• Net Weight of the Unit:28 Kg. (71.7 lbs.)
